ARIET GEL 6GFM-75 12V 75Ah (VRLA)

The ARIET 6GFM-75 is a reliable 12V 75Ah sealed gel battery designed for long-term service and deep discharge resistance, ideal for backup power systems without the need for maintenance.

SKU: GEL 6GFM-75 Category: Series:
Application

Description

The ARIET GEL 6GFM-75 battery is built using advanced GEL technology, featuring a gelled electrolyte that prevents leaks and allows for safe operation in any position. The unit is housed in a durable, flame-retardant ABS plastic casing, ensuring high safety standards and environmental protection by eliminating gas emissions under normal natural ventilation.

With a nominal voltage of 12V and a capacity of 75Ah, this battery offers a service life of 10–12 years in standby mode. It is characterized by high temperature stability, a low self-discharge rate (3% per month), and exceptional recovery capabilities after deep discharges. The internal design includes lead dioxide positive plates and lead negative plates, with brass terminals for reliable conductivity.

The compact dimensions (260 x 168 x 211 mm) and weight of 23.5 kg make it a versatile choice for professional power setups. It operates effectively across a wide temperature range, from -20°C to +60°C during discharge, ensuring reliable performance in demanding environments.

Parameter Value
CHARGING PARAMETERS
Cyclic mode (14.1 - 14.4 V/cell) Max. charging current: 18.7 A
Max. discharge current (25°C) 700 A
Temperature compensation (cycle) 18 mV/cell
Float mode (13.5 - 13.8 V/cell) Temperature compensation: 18 mV/cell
MAIN CHARACTERISTICS
Nominal voltage 12 V
Number of cells 6
Service life (at t = 20 ± 5°C) 10-12 years
Internal resistance (25°C) 4.8 mOhm
Self-discharge (at 25°C) 3% capacity per month
NOMINAL CAPACITY (25°C)
10-hour discharge (7.5 A; 10.8 V/cell) 75 Ah
5-hour discharge (13.0 A; 10.5 V/cell) 64,8 Ah
1-hour discharge (46,4 A; 9.9 V/cell) 46,4 Ah
OPERATING TEMPERATURE RANGE
Discharge -20 ~ +60°C
Charge -10 ~ +50°C
Storage -20 ~ +60°C
DIMENSIONS (±2mm) AND WEIGHT
Length 260 mm
Width 168 mm
Height 211 mm
Full Height 217 mm
Weight (±3%) 23.5 kg
Component Material
Positive plate Lead dioxide
Negative plate Lead
Container ABS
Cover ABS
Safety valve Acid-resistant rubber
Terminal Brass
Separator GEL
Electrolyte Sulfuric acid solution in gel form

Technical Specifications - ARIET Gel 6GFM-75_En

Преимущества
The VRLA battery will feature an enclosure made of a self-extinguishing material.
GEL
Long service lifetime
ELECTROSTATIC DISCHARGE IMMUNITY
Connections with other Equipment
Natural Ventilation System;
Not required
Stability of characteristics
Advantages
The VRLA battery will feature an enclosure made of a self-extinguishing material.
GEL
Long service lifetime
ELECTROSTATIC DISCHARGE IMMUNITY
Connections with other Equipment
Natural Ventilation System;
Not required
Stability of characteristics
